| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | Rexroth |
| 모델 번호: | A10VSO 71 DRS/32R-VPB22U99-S218 |
| 최소 주문 수량: | 1 PC |
| 가격: | US$1000-3000 PCS |
| 포장 세부 사항: | 80X37X49 센티미터 |
| 배달 시간: | 지불금을 받기 후에 2 일 안에 |
| 지불 조건: | L/C (신용장), 전신환, 웨스트 유니언 |
| 공급 능력: | 달 당 500 조각 |
| 타이핑하세요 :: | 수압 펌프 | 애플리케이션 :: | 굴삭기 |
|---|---|---|---|
| 이점:: | 공장 가격 | 펌프 유형 :: | 피스톤펌프 |
| 용법 :: | 유압 장비 | 차원(L*W*H): | 40*30*30 센티미터 |
| 치환: | 100 | 특징 :: | 장수 |
| 하이 라이트: | 32R-VPB22U99-S218 축 방향 피스톤 Pump,A10VSO 71 DRS 축 방향 피스톤 펌프,굴삭기 축 방향 피스톤 펌프 |
||
Axial piston unit of bent axis design with fixed displacement,for use as either pump or motor in hydrostatic drives,in open or closed circuit.
if operated as a pump,the flow is proportional to the drive speed and displacement.
if operated as a motor,the output speed is proportional to the swept volume and inversely proportional to displacement.
The output torque increases with the pressure drop between the high and low pressure sides.
The characteristics of Blince A2F A2FO/M piston pump:
1.Completely interchangeable with original.
2.Self-centering spherical control area allows torque free cylinder bearing.
3.Low peripheral speed and high efficiency.
4.Robust rolling bearings endure long service life.
5.Drive shaft capable of accepting radial loading.
6.Low noise level.
7.ISO standard mounting flange/shaft size/port size.
| specifiion | 10 | 28 | 45 | 71 | 100 | 140 | |||
| Displacement | Vg max | cm³ | 10.5 | 28 | 45 | 71 | 100 | 140 | |
| Maximum speed at Vg max | No max | rpm | 3600 | 3000 | 2600 | 2200 | 2000 | 1800 | |
| Maximum speed |
When the import pressure Pabs increases or Vg
|
No max zul | rpm | 4300 | 3600 | 3100 | 2600 | 2400 | 2100 |
| Maximum volume flow | At no max | Qv max | L/min | 37 | 84 | 117 | 156 | 200 | 252 |
| At nE=1450r/min | L/min | 15 | 42 | 68 | 107 | 150 | 210 | ||
| Maximum power(Δp=250bar) | At no max | Po max | kW | 16 | 39 | 55 | 73 | 93 | 118 |
| At nE=1450r/min | kW | 6.5 | 20 | 32 | 50 | 70 | 98 | ||
| Maximum torque(Δp=250bar) | At Vg max | Tmax | Nm | 125 | 125 | 200 | 316 | 445 | 623 |
| Moment of inertia | J | Kgm² | 0.0006 | 0.0017 | 0.0033 | 0.0083 | 0.0167 | 0.0242 | |
| Shell volume | L | 0.2 | 0.7 | 0.1 | 1.6 | 2.2 | 3.0 | ||
| weight | m | kg | 8 | 15 | 21 | 33 | 45 | 60 | |
| Maximum axial force | Fax max | N | 400 | 1000 | 1500 | 2400 | 4000 | 4800 | |
| Maximum radial force | Fq max | N | 250 | 1200 | 1500 | 1900 | 2300 | 2800 |
A: We are manufacture.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
A: As long as the valves are from Chengdu Yiyu technology company, we promise that the minimum period quality assurance is half year. If the products have any problem on quality within this period, we all provide exchange service. If they have been installed, inconvenient to be exchanged, we will provide technical personnel to help solve the problem.
A: We provide unified wholesale price to customers. No matter you buy one or hundreds of valves, we try our best to give you benefit, because we want to establish long-term cooperation relationship with you.
